Paradigm Cinema 100 3.0 System (System)

Superior 8˝ High-Excursion Driver made of a durable reinforced polymer composite that in concert with the superior suspension system and motor/magnet structure allow the cone to travel farther while maintaining effective control.

Built-In High-Current, Discrete Output Amplifier:
300 watts Dynamic Peak / 100 watts RMS Sustained.

Dual Ported Design for even and articulate response.

Amplifier Controls:
Auto On / Standby / Soft Clipping
Subwoofer Cut-Off Frequency
Sub / Sat Phase Switch – 0° or 180°

Design

• 2-driver, 2-way acoustic suspension, mineral-filled polymer enclosure

Crossover

• 2nd-order electro-acoustic at 1.8 kHz

High Frequency Driver

• 25-mm (1 in) S-PAL™ dome tweeter, ferro-fluid damped and cooled

Frequency Response On-Axis

• ±2dB from 125 Hz – 20 kHz

Frequency Response 30° Off-Axis

• ±2dB from 125 Hz – 15 kHz

Mid/Bass Frequency Driver

• 102-mm (3-1/2 in) mineral-filled polypropylene cone
• 25-mm (1 in) high-temperature voice coil
• Advanced motor structures and oversized ferrite magnets

Sensitivity Room / Anechoic

• 88 dB / 85 dB

Low Frequency Extension

• 85 Hz (DIN)

Suitable Amplifier Power Range

• 15 – 100 watts

Maximum Input Power

• 50 watts

Impedance

• Compatible with 8 ohms

Finishes

• Black Gloss

Dimensions (H x W x D)

• 8.375″ × 4.8125″ × 6.8125″ (21.3cm × 12.2cm × 17.3cm)

Weight

• 4 lbs. (1.8 kg)
